3-tie venttiili Dn25 Kv 12 moottorilla

MIX M 3 - 25 3-tie venttiili Dn25 Kv 12 + actuator MP06 135sek 5Nm

• koko: 1” Dn25 Kv 12
• tiiviste: 2 x O-rings EPDM
• runko: brass Ms CW617N
• akseli: brass Ms CW617N
• kääntö: 90°
• Max paine: 10 bar
• Max lämpötila: 110° C
• Moottori/Actuator:
• Nominal voltage: 230 V, +/- 15V, 50/60 Hz, or 24 V, +/- 15V, 50/60 Hz,
• Power consumption: 3,5 W; 3,5VA
• For wire sizing: wire, 3 x 0,75mm2, length - 2m
• Torque: 10 Nm (for nominal voltage)
• Angle of rotation: 90 Degrees, unregulated
  Running time:
• 70, 140 seconds for the voltage 230 VAC
• 140 seconds for the voltage 24 VAC
• Noise level: max. 35 dB (A)
• Position indicator: stuck on the handle body
• Protection class: II
• Degree of protection: IP 40
• Operating Temperature Range: 0 - 50°C
• Weight: 350 g
