Activated carbon filter d125

Activated carbon filter d125. The smog filter is designed for effective filtration of the so-called particulate matter. The PM2.5 and PM10 particles are the main component of smog, which have an optical diameter of 2.5 and 10 μm (micrometers). The filtration efficiency (removal) of PM2.5 particles reaches up to 73%, and PM10 particles up to 81% (according to tests carried out with a dust particle measuring device). The smog duct filter consists of a sealed filter box and two filters: prefilter and smog filter. It is recommended to install a smog filter on the supply ducts in domestic ventilation and heat recovery systems.

In the MOCarz-CA version prefilter I3 was replaced by an activated carbon prefilter (or activated charcoal). The main purpose of using such a material is deodorization of air and preliminary cleaning of dust and gaseous pollutants. Activated carbon has a huge adsorption surface, which effectively "binds" on its surface particles of pollutants, bacteria, hydrocarbons.

Filter replacement (filter set for 1 filter box):

FSBQ-I3 - prefilter

FSBQ-W-CA - prefilter with activated carbon ISO Coarse 65% MOCarz-W - proper filter - ISO ePM1 80% (EN-ISO 16890)
