Description
VMR 3-way valve with el. motor
Dn20
Nominal diameter DN 16
Nominal flow rate Kvsm3/h 7,8
Rated pressure PN 10
Max. working temperature t max 110°C
Max. diff. pressure Dpmax 154 kPa
Voltage U 230V;
Frequency 50/60 Hz
Absorbed power P 5 W
Degree of protection IP 20
Max. room temperature tpro 60°C
Aux. contact capacity 3A,250V
Openingtime 20 s, closing time s 6
Features
- Model: 4170
- Shipping Weight: 2lbs
- Manufactured by: MUT meccanica tovo (IT)
